FRONIUS TransSteel 3000 Compact PULSE

NO COMPROMISES. TRANSSTEEL MULTIPROCESS.

ONE DEVICE – FOR ALL MANUAL WELDING APPLICATIONS

Combining MIG/MAG, TIG, and electrode welding in one device means you no longer have to purchase any other power sources. There is absolutely no difference in the welding performance of the respective process compared with a dedicated device.

118 CHARACTERISTICS*

Steel, CrNi, AlMg, AlSi, Metal Cored, Rutil FCW, Basic FCW, self-shielded wires

0.8 – 1.2 mm wire diameter

Eight different gas mixtures

READY TO WELD IN THREE STEPS

The intuitive operating concept enables welders to start work straight away – no prior knowledge of the device is required. All the essential welding parameters can be viewed and adjusted on the front panel. The only parameters that have to be selected before welding begins are the gas, wire diameter and material thickness.

70% LESS REWORK, 30% FASTER WELDING

The Pulse function of the TransSteel 3000C permits faster welding speeds on thicker materials. The pulsed arc also reduces the amount of rework, as less welding spatter is generated.

* Maximum number of characteristics (TransSteel 3000 C Pulse), will vary depending on the version.

THE MIG/MAG WELDING FUNCTIONS

PULSE
WELDING CONTROLLED AND FAST

The new TransSteel 3000C Pulse marks the arrival of the pulsed arc in the TransSteel series. The setting is simply selected from the main menu and facilitates controlled welding in the intermediate arc range.

SPOT AND STITCH
WELDING WITH NO MATERIAL DISTORTION

Spot mode enables you to place welding spots at regular intervals. As you have complete flexibility over the pause time between the intervals, spot welding is ideal for the tacking of workpieces. Stitch welding not only produces a rippled seam appearance, the low level of heat input reduces any possible material distortion when working with light gage sheets.

SPECIAL 4-STEP
MODE FOR A MORE STABLE ARC

The “Special 4-step mode” is particularly suitable for welding in the higher power range. In special 4-step mode, welding starts at a lower power, which makes the arc easier to stabilize.

SYNCHROPULSE
SEAM RIPPLING FOR ALUMINUM ALLOYS

The “SynchroPulse” option is recommended for the welding of aluminum alloys when a rippled seam appearance is required. This effect is achieved by modifying the welding power between two operating points.! SynchroPulse works in Standard Synergic and Pulse Synergic Mode – but only on the TransSteel 3000C Pulse

STEEL TRANSFER TECHNOLOGY

/ STEEL is the universal characteristic for quick and easy welding applications.

/ STEEL ROOT is the characteristic specifically developed for root pass welding. It is characterized by particularly strong gap-bridging ability, in other words, the ability to fill wide gaps.

/ STEEL DYNAMIC is a characteristic with a particularly hard and concentrated arc, resulting in high welding speeds and deep penetration.

/ PCS (Pulse Controlled Spray Arc) characteristics* facilitate a combination of intermediate and spray arcs – the result is deep penetration with minimal spattering.

* TransSteel 3000C Pulse

CORRECTIONS DURING WELDING

The arc length correction and arc-force dynamic welding parameters can be used to optimize the welding result.

ARC LENGTH CORRECTION
TO CHANGE THE ARC CHARACTERISTIC

– shorter arc, reduced welding voltage
o neutral arc
+ longer arc, increased welding voltage

ARC-FORCE DYNAMIC
FOR INFLUENCING THE SHORT-CIRCUITING DYNAMIC AT THE INSTANT OF DROPLET TRANSFER

– hard, stable arc
o neutral arc
+ soft, low-spatter arc

PULSE CORRECTION
FOR CORRECTING THE PULSE ENERGY OF PULSED ARC

– Slower droplet detachment force
o neutral droplet detachment force
+ higher droplet detachment force

PACKAGE INCLUDES

• TransSteel 3000 Compact PULSE 4R/FSC & 4 off feeder rollers

• Earth Cable 50mm sq 4m & clamp

• Torch MTG320i/FSC/3.5m/45° - gas cooled

• Torch basic kit for steel wire (BK Fe Ø1.2/G/W/5m)

• Three phase plug
